Functions
Print, Scan, Copy, Fax
Basic Specs
Printer Type: Laser Printer
Product Dimensions (Width × Depth × Height): 417 mm × 461 mm × 448 mm
Weight: 14.9 kg
Print Speed: Up to 48 (A4) / Up to 50 (Letter) ppm
Paper Type: Plain Paper, Letterhead, Coloured Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env.Thin, Env.Thick
Paper Size: A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195 × 270 mm), A4 Short (270 mm Paper), COM-10, DL, C5, Monarch
Maximum Paper Capacity: Up to 1,390 sheets of 80 gsm plain paper (with Added Optional Trays)
Resolution: Up to 1200 × 1200 dpi
2-Sided (Duplex) – Printing Paper Type: Plain Paper, Letterhead, Coloured Paper, Thin Paper, Recycled Paper
2-Sided (Duplex) – Paper Size: A4, Letter, Legal, Mexico Legal, India Legal, Folio (Paper sizes other than A4 are supported only in some countries.)
Paper Handling
Tray #1 – Maximum Paper Weight: 60 to 163 gsm (16 to 43 lb)
Tray #1 – Maximum Paper Capacity: Up to 250 sheets of 80 gsm plain paper
Tray #1 – Paper Size: A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195 × 270 mm), A4 Short (270 mm Paper)
Tray #2 – Maximum Paper Weight: 60 to 120 gsm (16 to 32 lb)
Tray #2 – Maximum Paper Capacity:
LT-5505: Up to 250 sheets of 80 gsm plain paper
LT-6505: Up to 520 sheets of 80 gsm plain paper
Multi-purpose Tray – Maximum Paper Weight: 60 to 230 gsm (16 to 60 lb)
Multi-purpose Tray – Paper Size: Width: 69.8 to 215.9 mm (2.75″ to 8.5″), Length: 127 to 355.6 mm (5″ to 14″), Envelope: COM-10, DL, C5, Monarch
Multi-purpose Tray – Maximum Paper Capacity: Up to 100 sheets of 80 gsm plain paper
Automatic Document Feeder (ADF) Maximum Paper Capacity: Up to 50 sheets of 80 gsm plain paper
Paper Output:
Up to 150 sheets of 80 gsm plain paper (face-down output tray)
1 sheet (face-up output tray)
Copy
Colour/Monochrome: N/A / Yes
Enlarge/Reduce: 25% to 400% (in increments of 1%)
Resolution: Up to 1200 × 600 dpi
Scan
Colour/Monochrome: Yes / Yes
Resolution – Interpolated: Up to 19,200 × 19,200 dpi (interpolated) (Windows Only)
Resolution – Scanner Glass: Up to 1200 × 1200 dpi
Resolution – Automatic Document Feeder (ADF): Up to 600 × 600 dpi
Document Scanning Width/Length – Scanner Glass: Width: Up to 216 mm, Length: Up to 300 mm
Document Scanning Width/Length – Automatic Document Feeder (ADF): Width: 105 to 215.9 mm, Length: 147.3 to 355.6 mm
1-Sided (Simplex) – Scan Speed: Up to 28 (Mono) / Up to 20 (Colour) ipm
2-Sided (Duplex) – Scan Speed: Up to 56 (Mono) / Up to 40 (Colour) ipm
Fax
Compatibility: ITU-T Super G3
Modem Speed: 33.6 Kbps
Memory Transmission: Up to 500 pages (ITU-T Test Chart #1, Standard Resolution, JBIG)
Fax Forwarding: Yes
Out of Paper Reception: Up to 500 pages (ITU-T Test Chart #1, Standard Resolution, JBIG)
PC Fax – Sending: Yes (Mono)
PC Fax – Receiving: Yes (Mono)
Connectivity
Connectivity: Hi-Speed USB 2.0, 10Base-T/100Base-TX/1000Base-T
Network
Wireless Network Security: WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES); Wi-Fi Direct supports WPA2-PSK (AES) only
Wireless Setup Support Utility – WPS: Yes
Display & Memory
Display Type: 3.5″ Colour Touchscreen LCD
Memory Capacity: 1 GB
Operation
Power Source: 220 – 240 V AC, 50/60 Hz
Power Consumption – Printing: Approximately 680 W (For Taiwan) / Approx. 670 W (Except for Taiwan)
Power Consumption – Ready: Approximately 31 W
Power Consumption – Sleep: Approximately 5.9 W
Power Consumption – Power Off: Approximately 0.05 W
Noise Level: 54.0 dB (A)
Supported Operating Systems
Supported OS: Windows 10, Server 2012 / 2012 R2 / 2016 / 2019
Software and Apps
Included Software: BRAdmin Professional 4, iPrint&Scan
Mobile Apps: Mobile Connect
